Ground Screw Solar Mounting System

HZ ground screw solar mounting system is a highly pre-installed system and uses high-strength materials.
It can even handle with strong winds and thick snow accumulation, ensuring the overall safety of the system. This system has a wide trial range and high adjustment flexibility, and it can be used for installation on slopes and flat ground.


  • 10-year Quality Warranty
  • 25 Years Service Life
  • Structural Calculation Support
  • Destructive Testing Support
  • Sample Delivery Support

Product Detail

Product Tags

Product Application Examples



 Easy Installation

We continuously optimize the structural design of the system products.The total number of parts of the product is small and there are few link bolts, so the installation of each connection is simple.At the same time, most materials are pre-installed, which can save a lot of working time and installation labor costs on site.

Suitable for Slopes

The connection between the pillar and the beam adopts a unique patented design, which can adjust the east-west angle and the north-south angle at the same time, making it suitable for installation on inclined slopes.

Flexibility and Adjustability

When designing the system, the convenience and practicality of construction and installation were fully considered. The entire system has reserved many adjustable functions to facilitate construction such as height adjustment of ground piles and front and rear adjustable column connectors.

High Strength

The system uses high-strength materials, and the vertical rails are fixed at four points to make the connection nearly rigid. At the same time, the fixed clamps of the solar modules have their own error-proof design to prevent the modules from being blown by the wind due to incorrect installation of the clamps.

Cost-effective System

The frame system adopts the design scheme of the cross beam and the vertical rail to ensure high mechanical utilization rate of each component and it is cost-effective.

ground- mount-panel-kit

Technische Daten

Type Ground
Foundation Ground screw
Installation Angle ≥0°
Panel Framing Framed
Panel Orientation Horizontal
Design Standards AS/NZS,GB5009-2012
JIS C8955:2017
EN1991,ASCE 7-10
Aluminum Design Manual
Material Standards JIS G3106-2008
JIS B1054-1:2013
ISO 898-1:2013
Anti-corrosion standards JIS H8641:2007,JIS H8601:1999
ASTM B841-18,ASTM-A153
ASNZS 4680
Bracket Material Q355、Q235B (hot-dip galvanized)
 AL6005-T5 (surface anodized)
Fastener Material Zinc-nickel alloy
 stainless steel SUS304 SUS316 SUS410
Bracket Color Natural silver
Can also be customized (black)
